Vibro-Flow 5

Precision Feed Solutions Tailored for Vibro® Filtration

Product image of an industrial-size Vibro filtration unit by Sani Membranes connected to its matching feed system

three operation modes

automatic mode with permeate control

Flux or TMP controlled by permeate pump; system pressure controlled by feed pump

automatic mode without permeate control

TMP controlled by feed pump

manual mode

Direct pump and Vibro-I Drive control

process development

The Vibro-Flow 5 is a compact, stainless‑steel processing solution engineered to unlock the full potential of the patented Vibro® Membrane Filtration technology.

The system is designed for use with 2.5/5 m² Vibro‑I cartridge and is ideal for both process development and small‑scale manufacturing.

The system comes equipped with positive displacement feed and permeate pumps, pressure/flow/temperature monitoring, built in safety interlocks, and adjustable user alarm functions for safe and reliable operation.

Superior yield. Gentle processing.

The optional permeate control feature ensures precise regulation of either TMP or flux. By actively adjusting the permeate pump, the system maintains uniform membrane performance.

Combining low energy consumption and minimal shear impact,  the Vibro‑Flow 5 provides an optimal, reliable, and product‑friendly filtration process, perfectly suited for even the most sensitive media.

Specifications

Weight140 kg
Compatible Equipment
Vibro-I Drive with 2.5 or 5 m² cartridge
Feed PumpImpeller pump
Permeate PumpPeristaltic Pump

Data Logging & Alarms		Stores approx. 800 data points
Alarm log stores latest 25 alarms
USB Key included for backup

Temperature & Pressure Limits

Feed*
0 – 4 bar(g) at 5 – 35 °C
0 – 3 bar(g) at 35 – 55 °C
0 – 1 bar(g) at 55 – 80 °C
Permeate**0 – 2 bar(g)

*High level alarms and interlocks protect against overpressure.
**Pressure safety relief valve at 2.5bar(g) and high level alarm with interlock at 2 bar(g) to protect against overpressure.

Materials

Frame304 stainless steel
Piping
316 stainless steel
Media ContactFood grade

Instrumentation

RetentateFlow / conductivity / pressure
PermeateFlow / conductivity / pressure
FeedPressure / temperature

Liquid Connections

Triclamp K50.5Feed inlet & outlet to Vibro-I unit
Retentate outlet & inlet from vibro
Feed drain
Safety Valve Drain
Mini Clamp K25Permeate inlet from Vibro-I unit permeate outlet to permeate collection tank
½” Hose barb connectionVent pipe

Electrical Connections

Power SupplyCEE plug, 5-pin (3P+N+PE; N not used), 16 A, 400V
Output to Vibro-I Drive7-pin industrial connector
Feed system for 2.5 and 5m2 dimensions
Feed system for 2.5 and 5m2 dimensions
